Zhichun Wall-Mount Android Panel PC offers the versatility of a touchscreen display combined with the power and functionality of the Android operating system.
With their easy wall mount capability and wide range of applications, these devices are increasingly popular in various industries and environments.
Zhichun 15.6 inch Wall-Mount Android Panel PC offers the versatility of a touchscreen display combined with the power and functionality of the Android operating system
Advantages
1. Industrial Grade Components and Fanless Designs
2. Frontal panel reach IP65 waterproof and dust-proof
3. Capacitive touch screen design (G+G), support 10-point touch
4. LED back light, Brightness 300 nits, available to upgrade to 1000 nits
5. Metal shell, sturdy and durable
6. Suitable for wall-mounting/ VESA mounting
7. Multi-I/O connection: HDMI,USB, LAN, SIM slot, TF card slot, DC port, Audio (support customized)
8. Suitable for various of application industry
PRODUCT INTRODUCTION
What can Zhichun 21.5 inch Wall-Mount Android Panel PC help you
The Zhichun 21.5 inch android wall tablet pc is an innovative fusion of modern technology and sleek design, specifically engineered to enhance the interactive experience in various settings, from homes to offices, retail spaces, and industrial environments. This cutting-edge device capitalizes on the intuitive nature of a responsive touchscreen, paired with the versatility and extensive application support of the Android operating system.
With its generous 21.5 inch display, it provides ample workspace for multitasking, entertainment, or information display purposes. The wall-mount capability ensures space efficiency, making it a perfect fit for areas where desk space is limited or a streamlined look is desired. Its Android OS offers access to millions of apps from Google Play Store, enabling users to customize their experience with productivity tools, educational software, or even gaming and multimedia applications.
Built for durability and performance, this panel PC boasts robust hardware specifications that can handle demanding tasks effortlessly. It supports Wi-Fi and Bluetooth connectivity, ensuring seamless integration into existing networks and allowing for wireless peripherals and internet access. Security features inherent to Android further safeguard user data and privacy.
Whether it's for digital signage, conference room presentations, home automation control, or as an interactive kiosk,
the Zhichun Wall-Mount Android Panel PC delivers a seamless, user-friendly interface that combines style with substance,
redefining the way we interact with technology in our daily lives.
Zhichun industrial android panel pc typically consists of a touchscreen display, similar to a tablet,
but with a larger screen size that ranges from 7 inches up to 21 inches or more.
The display is mounted on a sturdy chassis that can be easily mounted on a wall or any other flat surface.
PRODUCT SPECIFICATIONS
Basic Parameter
| Sizes | 21.5 inches |
| Resolution | 1366*768(1920*1080) |
| Back light | LED |
| Brightness | 300nits |
| Dynamic contrast | 1000:1 |
| Touch screen | Capacitive touch |
| Touch point | 10-point touch |
| Respond Time | ≤5ms |
| Luminousness | 85±5% |
| Surface Hardness | 6H |
| Click Lifetime | 50 millions times |
| Viewing Angle | R/L:65(Typ.), U/D:65(Typ) |
| Communication Interface | USB interface |
| Operating System | Android 7.1/8.1/9/11/12 |
| Processor | RK3288 (RK3399/RK3568/A311D optional) |
| RAM | 2GB (4GB/8GB optional) |
| ROM | 8GB eMMC (16GB/32GB/64GB optional) |
I/O Interface
| USB | 2*USB |
| Display out | 1*HDMI |
| LAN | 1*RJ45(Gigabit Ethernet) |
| 4G LTE | 1*SIM slot(4G module optional) |
| Extended storage | 1*TF card slot |
| Audio | 1*Line-out |
| Power | 12V DC power input |
Environmental Parameters
| Operating Temperature | -10－+60 |
| Storage Temperature | -20－+70 |
| Relative Humidity | 20%－90% |
General Parameters
| Outline Dimension | 391*240*44mm(L*W*H) |
| Display Dimension | 344.5*193.5mm(L*W) |
| Mounting Hole Size | 100*100mm |
| Shell Material | Metal cover |
| Installation Type | Wall-Mounted, Desktop, VESA |
Optional Configuration
| Motherboard Optional | RK3288 | RK3399 | A311D | RK3568 | ||||
| Version Optional | Android 7.1 | Android 8.1/9/11 | Android 9 | Android 11/12 | ||||
| RAM Optional | 2GB/4GB | 2GB/4GB | 4GB/8GB | |||||
| ROM Optional(eMMC) | 8GB/16GB/32GB | 16GB/32GB/64GB | 16GB/32GB/64GB | |||||
ORDERING INFORMATION
Free accessories
| Accessory | Description |
| Embedded buckle | 4 pcs of embedded buckles+ 4 pcs of screws |
| Adapter | 1 pcs of 12V/5A adapter |
| Power cord | 1 pcs of 1.5m |
| HDMI cable | 1 pcs of 1.5m |
| Touch pen | 1 pcs |
Optional accessories
| Accessory | Description |
| Power cord | 1 pcs of 3m/5m |
| Wall-mount plate | 1 pcs of wall-mount plate |
| Desktop stand | 1 pcs of desktop stand |
