5* Intel GBE LAN Intel core I3-11th Gen quad-core processor Mini PC for Visual industrial control computer
Advantages
Memory: optional 4GB/ 8GB/ 16GB DDR3 System Memory( DDR4 Optional)
Storage : optional 64GB/ 128GB/ 256GB/ 512GB SSD/ 500GB/ 1TB HDD
System: WIN7/10 pro/11 Pro (We will pre-install Win 10 pro COPY OS, I3-3227U could only support Windows XP OS)
1. Multi- I/O connection: HDMI,USB, LAN, SIM slot, TF card slot, DC port, Audio (support customized)
2. Support multi-OS: Windows 10/ Linux
3. Power supply support 9-36V DC, low consumption, TDP only 28W(12W/15W BIOS optional)
4. Support Video display output max resolution up to 4096x2160@24Hz
5. Support extension: Built in DDR4 Ram Slot, NVME SSD slot, 2.5 inch HDD slot, Msata slot, WiFi
6. Support 4*15W POE, Watchdog, Auto Boot, Wake On Lan, Diskless Boot, Resume by Alarm
7. Suitable for different harsh working envirment, operating temperature: -20°C to +60°C
8. Industrial Grade accessary Fanless Designs
9. Aluminum Alloy material shell, sturdy and durable, anti-corrosion
Style M mini IPC with 5xLAN port, 2xUSB3.0, 2xUSB2.0, HDMI, power switch, DC-24V, SIM, Phoenix terminal 24v, 4xCOM, 2xWiFi interface. Completed and rich interfaces can Conveniently connect more industrial control testing, communications, instrumentation and equipment to meet the needs of more than 90% Industrial control interface requirements, and can be customized industrial computer pc according to customer needs.
Introducing a powerful and compact Mini PC designed specifically for visual industrial control computer applications.
Equipped with a cutting-edge Intel Core I3-11th Gen quad-core processor, this Mini PC offers exceptional performance and responsiveness. With its 5* Intel GBE LAN, it ensures lightning-fast network connections, enabling seamless data transfer and efficient communication in industrial environments. Its compact design makes it ideal for space-restricted areas, allowing for easy integration into existing setups. Whether it’s controlling complex visual systems or managing real-time data, this Mini PC is up to the task. Experience the perfect combination of power, reliability, and space-saving design with this top-of-the-line Mini PC.
Basic Parameter
| Sizes | 250*192*56.5mm |
| Net Weigh | 2.5KG |
| Operating System | Windows 10/ Linux |
| Processor | Integrated Intel®I3-1115G4/Max. 4.10GHz Duad-core 4 threads, TDP 28W |
| RAM | 8GB, Support DDR4 3200 MHz, 2 * non-ECC SO-DIMM Slot, Up to 64G |
| ROM | 128GB SSD, support 1*SATA3.0(7P)+1*M.2-M slot PCIex4 NVMe SSD 2242/2280 |
| GPU Graphic | Intel® UHD Graphics, up to 48 EUs, 1.25Ghz |
| WIFI | 2.4GHz WIFI |
| BT | BT4.0/BT5.2(optional) |
| Color | Sliver+black |
| Material/Structur | Aluminum alloy fanless |
| Mounting type | Desktop type/ Embedded type |
| System Chip | Base on Tiger Lake, integrated CPU |
| BIOS | AMI UEFI BIOS (Support Watchdog Timer) |
| Power | External Power Adapter or open power |
| Input Voltage | DC 24V |
| Output Power | 60W and more |
I/O Interface
| POWER | 1*Power switch, DC 24V Power Input Φ2.5mm Jack, 1 * ATX 4P Power Input Right Angle Connector |
| LAN | 5* Intel® I211-AT GBE LAN Chip(10/100/1000 Mbps, RJ45)，(Support 4*15W POE) |
| USB | 2*USB3.0, 4*USB2.0 |
| 4G | Support 4G/5G, with 1 * SIM Card slot, 4G/5G module card(optional) |
| Display Interface | 1 * HDMI(TYPE-A): max resolution up to 4096x2160@24Hz |
| COM | 4 * COM (2* RS232+2*RS232/RS485) |
| WIFI | 2.4 GHz WIFI |
| SATA3.0 | 1*2.5”HDD extend |
| M.2 | 1 * M.2 Key-M Slot( PCIe 4x NVMe SSD) |
| M.2 | 1 * M.2 Key-B Slot (3042/3052, Support 4G/5G) |
| M.2 | 1 * M.2 Key-E Slot (PCIE, Support WIFI+BT, 2230) |
Environmental Parameters
| Operating Temperature | 0℃～60℃ |
| Storage Temperature | -20℃～75℃ |
| Relative Humidity | 5%-95%, non-condensing |
| Operating vibration | 0.5g rms/5-500HZ/random/operating |
Optional Configuration
| CPU Optional | Intel Core: I5-1135G7/i7-1165G7 | ||||
| RAM Optional | 8GB/16GB/32GB/64GB | ||||
| ROM Optional | 128GB/256GB/512GB/1TB SSD | ||||
Free accessories
| Accessory | Description |
| Adapter | 1 pcs of 24V DC adapter |
| Power cord | 1 pcs of 1.5m |
Optional accessories
| Accessory | Description |
| Power cord | 1 pcs of 3m/5m |
| Wall-mount plate | 1 pcs of wall-mount plate |
| Desktop stand | 1 pcs of desktop stand |
