For example: 15 inch panel pc
1. Check this chart, find the size hole you need to open on box. Open a hole of 350*274 mm.
2. Panel mount the panel pc from outside to inside. Use both hand to hold on.
3. One hand to hold on, and the other hand use buckle to insert in the small hole.
4. The other side of the bucle need to connect the panel pc/monitor.
That's all. Then you can get a panel mount computer or monitor.
If you want to see the video, pls check this link: Install the panel pc in cabinet by panel mount.
Next, let me introduce our Zhichun Z style panel pc.
It can panel mount from outside to inside.
There is 2-3mm edge will leave on outsie.
The outside rim is silver color aluminum alloy material.
Can custom to black color.
Extra $30, lead time 7-15 days.
Most of buyer choose silver color because their cabinet is white color or stainless steel.
It looks better to use silver grey color rim.
But sometime they need black too, and we can custom too, don't worry.
If you use outside, its ok because IP65 waterproof.
But need to custom the screen to 1000 nits high brightness display for sunlight readable.
here is the prodcuts link for 1000 nits 15 inch high brightness touch screen monitor.
Here is a solution to use 21.5 inch panel pc with ubantu system. android RAM 2G SSD 8G
to play Advertisment on a EV Charger Station.
They also use the high brightness touch montior option.
